DUBULTAIS PĀRSPIEDIENA VĀRSTS 1/2 VAU 30-180

Description

dual pressure relief valve for MS series motors | type VAU 1/2" OMS | pressure relief valve is used to protect the system from damage caused by overpressure | both pressure lines have a common tank connection | material zinc-plated steel | setting range 30 – 180 bar (factory setting 90 bar) | adjustment 30 bar/revolution | connection V1 V2: G 1/2" | SF 1/4" | max. flow 50 l/min | max. operating pressure 350 bar

Attributes

Thread: G 1/4" -19, G 1/2" -14 | Package length (cm): 9 | Package width (cm): 3.5 | Package height (cm): 11 | Gross weight (kg): 1.501000 | EAN: 6418914078307
