Rullīšu ķēde 3/4 din8187
95 €
Noliktavā 6 prece/-es
✓ Pieejams
Description
P pitch: 3/4" | Dr roller Ø: 12,07 mm | W inner width min.: 11,68 mm | Hi hight max.: 16,13 mm | S thickness: 1,85 / 1,70 mm | Dp pin diameter max.: 5,72 mm | A1 width of riveted pin: 22,50 mm | B width of pin: 30 mm | working surface: 89 mm² | measuring load: 280 N | min. breaking strength: 28,90 kN | average breaking strength: 33,00 kN | weight: 1,21 kg | economic product
Attributes
Package length (cm): 100 | Package width (cm): 3 | Package height (cm): 3 | Gross weight (kg): 1.268000 | EAN: 6418914089402
