PLŪSMAS NOVADĪTĀJS 6/2 1/2 1/2 24V
225 €
✓ Pieejams
Description
voltage 24 V | connections 1/2" BSP | max. flow 70 l/min | max. pressure 310 bar | the schematic diagram shows the electrical and hydraulic parts of the system | when connecting the valves to each other, we recommend using hexagon head screws M8 DIN912 hardness 8.8 (min) | screw length 125 mm for two valves, 190 mm for three valves (tightening torque 15-16 Nm) | spare part solenoid FM2523
Attributes
Thread: G 1/2" -14 | Package length (cm): 21.3 | Package width (cm): 10 | Package height (cm): 6.5 | Gross weight (kg): 4.104000 | EAN: 6418914741454
