Radiālais lodīšu gultnis 60 mm skf
182 €
✓ Pieejams
Description
bore diameter (d) 60 mm | outer diameter (D) 90 mm | nominal width (B) 44 mm | outer ring width (C) 36 mm | angle of tilt (α) 6 ° | raceway diameter inner ring (dk) 80 mm | width annular lubrication groove at outer ring (b) 6.2 mm | width annular lubrication groove at inner ring (b1) 6.4 mm | diameter of lubrication hole (outer ring) (M) 4 mm | chamfer dimension, bore (r1) min. 1 mm | chamfer dimension outer ring (r2) min. 1 mm | abutment shaft diameter (da) min. 66.4 mm | abutment shaft diameter (da) max. 66.8 mm | abutment housing diameter (Da) min. 79.7 mm | abutment housing diameter (Da) max. 84.2 mm | fillet radius , shaft (ra) max. 1 mm | fillet radius, housing (rb) max. 1 mm | basic dynamic load rating (C) 245 kN | basic static load rating (C0) 1220 kN | specific dynamic load factor (K) 100 N/mm² | specific static load factor (K0) 500 N/mm² | material constant (KM) 330
Attributes
Inner diameter Ø (mm): 60 | Inner diameter Ø (mm): 60.00 | Outer diameter Ø (mm): 90 | Outer diameter Ø (mm): 90.00 | Package length (cm): 9.5 | Package width (cm): 10.2 | Package height (cm): 6 | Gross weight (kg): 1.006000 | EAN: 7316576609435
