PUSH-IN SAVIENOJUMS 8MM-3/8 ĀRĒJĀS TAPAS R1

Description

straight cylindrical push-in fitting with male thread (RL1) | material brass | with O-ring seal | operating pressure -0.99 – 16 bar | operating temperature -20…+80 °C | fluid: vacuum, compressed air | recommended pipe: Rilsan PA 11, nylon 6, polyamide 12, polypropylene | pipe Ø 8 | F thread G 3/8" | CH 14 | CH1 6 | P 9 | L 22.8 | D 6.2 | E 22

Attributes

Thread: G 3/8" -19 | Package length (cm): 2.3 | Package width (cm): 2.2 | Package height (cm): 2.2 | Gross weight (kg): 0.019000 | EAN: 8024986123500
