Dziļfrēžu lodīšu gultnis 35x72x23 skf
94 €
✓ Pieejams
Description
bore diameter (d) 35 mm | outer diameter (D) 72 mm | width (B) 23 mm | inner ring shoulder diameter (d1) 47.5 mm | outer ring shoulder diameter (D1) 59.5 mm | chamfer dimension (r1,2) min. 1.1 mm | abutment shaft diameter (da) min. 42 mm | abutment housing diameter (Da) max. 65 mm | fillet radius (ra) max. 1 mm | basic dynamic load rating (C) 35.1 kN | basic static load rating (C0) 28.5 kN | fatigue load limit (Pu) 1,2 kN | reference speed 15000 r/min | limiting speed 8000 r/min | calculation factor (kr) 0.05 | calculation factor (f0) 14.3
Attributes
Inner diameter Ø (mm): 35 | Inner diameter Ø (mm): 35.00 | Outer diameter Ø (mm): 72 | Outer diameter Ø (mm): 72.00 | Package length (cm): 7.4 | Package width (cm): 7.6 | Package height (cm): 2.7 | Gross weight (kg): 0.407000 | EAN: 7316577004444
