Dziļfrēžu lodīšu gultnis 35x55x10 skf

Description

bore diameter (d) 35 mm | outer diameter (D) 55 mm | width (B) 10 mm | inner ring shoulder diameter (d1) 42.2 mm | outer ring abutment recess diameter (D2) 52.15 mm | chamfer dimension (r1,2) min. 0.6 mm | abutment shaft diameter (da) min. 38.2 mm | abutment shaft diameter (da) max. 41.5 mm | abutment housing diameter (Da) max. 51.8 mm | fillet radius (ra) max. 0.6 mm | basic dynamic load rating (C) 10.8 kN | basic static load rating (C0) 7.8 kN | fatigue load limit (Pu) 0,325 kN | reference speed 26000 r/min | limiting speed 13000 r/min | calculation factor (kr) 0.02 | calculation factor (f0) 15.7

Attributes

Inner diameter Ø (mm): 35 | Inner diameter Ø (mm): 35.00 | Outer diameter Ø (mm): 55 | Outer diameter Ø (mm): 55.00 | Package length (cm): 6.8 | Package width (cm): 6.8 | Package height (cm): 1.5 | Gross weight (kg): 0.085000 | EAN: 7316577095114
