Dziļfrēžu lodīšu gultnis 30x62x16 skf

Description

bore diameter (d) 30 mm | outer diameter (D) 62 mm | width (B) 16 mm | inner ring shoulder diameter (d1) 40.7 mm | inner ring abutment recess diameter (d2) 40.7 mm | outer ring abutment recess diameter (D2) 55.13 mm | chamfer dimension (r1,2) min. 1 mm | abutment shaft diameter (da) min. 35 mm | abutment shaft diameter (da) max. 40.5 mm | abutment housing diameter (Da) max. 57 mm | fillet radius (ra) max. 1 mm | basic dynamic load rating (C) 16.5 kN | basic static load rating (C0) 11.2 kN | fatigue load limit (Pu) 0,48 kN | limiting speed 7000 r/min | calculation factor (kr) 0.03 | calculation factor (f0) 13.9

Attributes

Inner diameter Ø (mm): 30 | Inner diameter Ø (mm): 30.00 | Outer diameter Ø (mm): 62 | Outer diameter Ø (mm): 62.00 | Package length (cm): 6.5 | Package width (cm): 6.5 | Package height (cm): 2 | Gross weight (kg): 0.204000 | EAN: 7316570779011
